MA-MB300
Technical Specifications
Parameter |
Specification |
|---|---|
| Voltage | AC100V~240V, 50/60Hz |
| Light Source | 300W white LED module |
| Lifespan | 20,000 hours |
| Color Temperature | 9000K |
| LED Light Core | 54 high-brightness 3-in-1 LED beads, built-in multiple racing effect programs; master-slave synchronous modes |
| Beam Angle | Zoom 0°~5°, 160mm large aperture output |
| Color | 14 colors + white light, full-color/ half-color/ linear color, variable speed bidirectional rainbow effect; built-in high-efficiency Hall sensor |
| Pattern | 1 fixed pattern plate: 15 patterns + 2 glass patterns + white light; bidirectional variable speed rotation with shaking and flow effects; built-in high-efficiency Hall sensor |
| Prism | 1 8-prism; 1 combinable prism (8+16+24 edges); stackable with bidirectional variable speed rotation |
| Soft Light | 1 soft light mirror + 1 six-color plate; linear adjustment 0–100% |
| Focusing | DMX linear focusing with automatic focusing function |
| Electronic Strobe | 0.3–25 times/second |
| Dimming | Electronic dimming with 0–100% linear adjustment |
| Rotation Angle | 540° horizontally, 270° vertically |
| Control Mode | 16/19CH, 2 channel modes; standard DMX512 and RDM protocols |
| Lamp Body Weight | 13.5 kg |
Description
MA-MB300 is a 300W professional moving beam light designed for stage, concert, and event production applications.
It is equipped with 54 × 3-in-1 LEDs featuring 14 colors + white rainbow effect, along with a 0°–5° beam zoom to produce sharp and powerful beams.
The fixture supports DMX512 & RDM control, 16 channel modes, and professional features such as a gobo wheel, combination prism, strobe, and auto focus, enabling dynamic and creative lighting effects.
